Oil & Gas Transmisson & Distribution
Synergy Systems & Solutions, has experience of over 25 years in the field of Oil & Gas automation - from refineries to pipelines to terminals. SSS provides in-house solutions for pipelines, terminal automation in conjunction with third-party hardware and software for a turnkey solution. SSS also has experience in simulation studies for oil transportation pipelines.
Solutions Offered
- Cross-country Pipeline monitoring-cum-control
- Terminal Automation
- Automated TT/Rail loading
- Rail Loading
- LPG loading / unloading
- Interface with ERP business logic
- Pump house & Tank Gauging automation
- Integration with ERP business applications over the web
Quick Facts
- SIRIUS based Control Centers - 3
- HUSKY RTUs Supplied – 250+
- All LPG pipelines of GAIL in India controlled & monitored by HUSKY RTU
Key Projects
Gas Authority of India Limited – RTUs for JLPL
Replacement of existing RTUs with HUSKY RTU for remote monitoring and control of pipeline facilities (despatch and receiving terminals, sectionalizing valves, intermediate pigging stations) across the 1300km long Jamnagar-Loni LPG pipeline, along with upgrade of communications to Ethernet from serial network.
PRODUCTS IMPLEMENTED
- HardwareHUSKY RTU
Highlights
- Total 79 RTU across the pipeline
- DNP3 Serial & TCP based communication in redundant mode
- Dual redundant CPUs and PSUs
- Reporting to two masters
- Interface with flow computers, gas chromatographs & solar panel
- Dual redundant CPUs and PSUs
Highlights
- The upgrade consisted of replacing existing PC hardware.
- ITAS was deployed to integrate all the automated facilities in the terminal.
- Batch Controllers
- Entry/Exit card readers
- Pump-house
- Tank gauging
- ERP
- Automated valve alignment operations
- MIS Reports
- Daily Product, Customer-wise Product, Batch controller-wise,
- Bay-wise Product Dispatch
- Tank Loss/Gain, Inventory, Pump Operations Report
- In satisfactory operation since 2003
IOCL Bijwasan – Terminal Automation System Upgrade
The terminal is a key installation for supply of white oil products in and around Delhi and to the Indira Gandhi International Airport. To upgrade the existing automation system and to integrate the three independent systems into one for better and efficient control and monitoring.PRODUCTS IMPLEMENTED
- SoftwareITAS
Indian Oil Corporation Limited – Control system for Mathura-Bharatpur Pipeline at Bharatpur
IOCL Matura Bharatpur pipeline is a spur line of approximately 21 KM originating at Mathura station of MTPL which lies inside Mathura Refinery. This spur line is used for delivery of petroleum products to the existing Marketing Terminal of IOCL at Bharatpur. The control system at Bhartpur is controlled by dual redundant PLC system along with SIRIUS SCADA. The local data of Bharatpur station, is also transmitted to Mathura, over Fiber Optic link.
PRODUCTS IMPLEMENTED
- SoftwareSIRIUS SCADA
Highlights
- Control System comprises of dual redundant PLC with SIRIUS SCADA
- Interfacing with various field instruments including PT, TT, Flow Computers
- PID loops, Batch Arrival and Batch Reports are standard part of the system
- UPS system integrated with SCADA over MODBUS
- Integration with Fire Alarm System
- Application-specific sequence control logics are programmed for performing PID control, interlock conditions checking, downtime calculations, product batch logging, etc.
- In Satisfactory Operation since 2009
Highlights
- The upgrade consisted of replacing existing PC hardware.
- ITAS was deployed to integrate all the automated facilities in the terminal.
- Batch Controllers
- Entry/Exit card readers
- Pump-house
- Tank gauging
- ERP
- Automated valve alignment operations
- MIS Reports
- Daily Product, Customer-wise Product, Batch controller-wise,
- Bay-wise Product Dispatch
- Tank Loss/Gain, Inventory, Pump Operations Report
- In satisfactory operation since 2003
GAIL Gujarat
The terminal is a key installation for supply of white oil products in and around Delhi and to the Indira Gandhi International Airport. To upgrade the existing automation system and to integrate the three independent systems into one for better and efficient control and monitoring.PRODUCTS IMPLEMENTED
- SoftwareITAS
